Rivco Risers install issues

[Walking Tall]

how much length did you have to add?

Good question



[Ishrub]

Rocket III clutch and dual pull/push throttle cables.

Throttle Cable 715.04.27 For Triumph Rocket 2300 III CLASSIC 2006 - 2008 | eBay

Find many great new & used options and get the best deals for Throttle Cable 715.04.27 For Triumph Rocket 2300 III CLASSIC 2006 - 2008 at the best online prices at eBay!

www.ebay.com.au

Throttle Cable 715.04.41 For Triumph Rocket 2300 III CLASSIC 2006 - 2008 | eBay

Triumph Rocket 2300 III CLASSIC 2006 - 2008. Ref: 715.04.41.

www.ebay.com.au

More to come...

Throttle Cable 715.04.40 For Triumph Rocket 2300 III 2004 - 2008 | eBay

Find many great new & used options and get the best deals for Throttle Cable 715.04.40 For Triumph Rocket 2300 III 2004 - 2008 at the best online prices at eBay!

www.ebay.com.au

Throttle Cable 715.04.26 For Triumph Rocket 2300 III 2004 - 2008 | eBay

Find many great new & used options and get the best deals for Throttle Cable 715.04.26 For Triumph Rocket 2300 III 2004 - 2008 at the best online prices at eBay!

www.ebay.com.au

Clutch Cable For Triumph Rocket 2300 III 2004 | eBay

Find many great new & used options and get the best deals for Clutch Cable For Triumph Rocket 2300 III 2004 at the best online prices at eBay!

www.ebay.com.au



[cdsumlin]

What I thought was going to be an easy upgrade has apparently been incredibly difficult. My '18 R3R has been in the shop since I high sided it back in November of last year. I asked them to install the Rivco's for me while the bike was there. Yesterday I got a call from the Service Department, multiple cables are too short, ABS break line's too short, even wiring may be too short. Am I getting fed a load of b.s. or do these 'bolt on' accessories really require all this additional work and expense to install? Any feedback would be appreciated as this is one of the final hurdles to getting my bike back after nearly a year in the shop.
W.T.

I did the upgrade on my 14, The hard lines under the coil on the right side are bolted to the frame. Both lines use a single bolt, but they have separate clips on them built into the junction that connects the hard lines to the flexible lines. I removed the single bolt and fabricated a bracket that allowed me to move the brake line about 3/4" to allow ample clearance. I did have to straighten the bends in the hardline, gently, but not much. The throttle and clutch cables were rerouted and had plenty of room. The wiring was not problem.



[9Ball]

Here’s a copy of my order from HEL. +2” brake lines with original routing of lines. The clutch cable, not listed, was +4” from Barnett.



[Ishrub]

Here’s a copy of my order from HEL. +2” brake lines with original routing of lines. The clutch cable, not listed, was +4” from Barnett.

As stated earlier by the OP he has an ABS Roadster and the HEL kit is a 6x hose kit for ABS Roadsters.
I have one in the shed.

Part Number: 6 HOSES HBF8014​

HEL BRAKE LINE KIT FOR TRIUMPH ROCKET III ROADSTER ABS (2011-2013) 6 HOSES, HEL, HEL335-6-HOSES-HBF

HEL - HEL335-6-HOSES-HBF8014-

www.cj-motor.com



[9Ball]

As stated earlier by the OP he has an ABS Roadster and the HEL kit is a 6x hose kit for ABS Roadsters.
I have one in the shed.

Part Number: 6 HOSES HBF8014​

HEL BRAKE LINE KIT FOR TRIUMPH ROCKET III ROADSTER ABS (2011-2013) 6 HOSES, HEL, HEL335-6-HOSES-HBF

HEL - HEL335-6-HOSES-HBF8014-

www.cj-motor.com

Yes, I know….just wanted to show that HEL makes the custom length lines in many colors and fittings. I directed him to check their website for his ABS application. He wanted to know how extra long the lines needed to be when installing the Rivco risers and the receipt shows that +2” worked well for me. I didn’t want to reroute the stock lines behind the triple tree as others suggested.



[Walking Tall]

Rocket III clutch and dual pull/push throttle cables.

Throttle Cable 715.04.27 For Triumph Rocket 2300 III CLASSIC 2006 - 2008 | eBay

Find many great new & used options and get the best deals for Throttle Cable 715.04.27 For Triumph Rocket 2300 III CLASSIC 2006 - 2008 at the best online prices at eBay!

www.ebay.com.au

Throttle Cable 715.04.41 For Triumph Rocket 2300 III CLASSIC 2006 - 2008 | eBay

Triumph Rocket 2300 III CLASSIC 2006 - 2008. Ref: 715.04.41.

www.ebay.com.au

More to come...

Throttle Cable 715.04.40 For Triumph Rocket 2300 III 2004 - 2008 | eBay

Find many great new & used options and get the best deals for Throttle Cable 715.04.40 For Triumph Rocket 2300 III 2004 - 2008 at the best online prices at eBay!

www.ebay.com.au

Throttle Cable 715.04.26 For Triumph Rocket 2300 III 2004 - 2008 | eBay

Find many great new & used options and get the best deals for Throttle Cable 715.04.26 For Triumph Rocket 2300 III 2004 - 2008 at the best online prices at eBay!

www.ebay.com.au

Clutch Cable For Triumph Rocket 2300 III 2004 | eBay

Find many great new & used options and get the best deals for Clutch Cable For Triumph Rocket 2300 III 2004 at the best online prices at eBay!

www.ebay.com.au

Do you know if any of those work on a 2018 Roadster?



[Walking Tall]

Usual dealer ****. If it ain't standard they can't or won't do it.

Yep. If I remember correctly, I suggested they put the risers on when the front end was disassembled to service the forks and swap the springs out. That would've been the best time to re-route cables and the brake line.



[Ishrub]

Do you know if any of those work on a 2018 Roadster?

The Classic and early 04-08 cables will fit the levers and end mounting points/connections of the Roadster and the Classic ones may be slightly longer from comments /posts in old threads as they came with floorboards and pull back bars requiring extra length. I have not compared mounting points for the R3Touring but they are likely different at bar end despite being longer than Roadsters for similar reasons to Classic but likely different connections.



[Ishrub]

Here is another supplier from Germany with available versions and pricing in Aussie and US $.
Aussie

throttle cable close for Triumph Rocket 2300 III CLASSIC # T2043581 4251317940404 | eBay

Triumph Rocket 2300 III Classic 2004 (C23XB). Triumph Rocket 2300 III Classic 2005 (C23XB). Triumph Rocket 2300 III Classic 2006 (C23XB). Triumph Rocket 2300 III Classic 2007 (C23XB). Triumph Rocket 2300 III Classic 2008 (C23XB).

www.ebay.com.au

US $

throttle cable close for Triumph Rocket 2300 III CLASSIC # T2043581 | eBay

Triumph Rocket 2300 III Classic 2004 (C23XB). Triumph Rocket 2300 III Classic 2005 (C23XB). Triumph Rocket 2300 III Classic 2006 (C23XB). Triumph Rocket 2300 III Classic 2007 (C23XB). Triumph Rocket 2300 III Classic 2008 (C23XB).

www.ebay.com

Aussie

throttle cable for Triumph Rocket 2300 III Touring # T2043585 4251317943047 | eBay

Triumph Rocket 2300 III Touring 2007 (23XC). Triumph Rocket 2300 III Touring 2008 (23XC). Triumph Rocket 2300 III Touring 2009 (23XC). Triumph Rocket 2300 III Touring 2010 (23XC). Triumph Rocket 2300 III Touring 2011 (23XC).

www.ebay.com.au

US $

throttle cable for Triumph Rocket 2300 III Touring # T2043585 | eBay

Triumph Rocket 2300 III Touring 2007 (23XC). Triumph Rocket 2300 III Touring 2008 (23XC). Triumph Rocket 2300 III Touring 2009 (23XC). Triumph Rocket 2300 III Touring 2010 (23XC). Triumph Rocket 2300 III Touring 2011 (23XC).

www.ebay.com

Aussie

throttle cable open for Triumph Rocket 2300 III # 2004-2014 # T2043570 4251317940381 | eBay

Find many great new & used options and get the best deals for throttle cable open for Triumph Rocket 2300 III # 2004-2014 # T2043570 at the best online prices at eBay!

www.ebay.com.au

US $

throttle cable open for Triumph Rocket 2300 III # 2004-2014 # T2043570 | eBay

Triumph Rocket 2300 III 2004 (C23XB). Triumph Rocket 2300 III 2005 (C23XB). Triumph Rocket 2300 III 2006 (C23XB). Triumph Rocket 2300 III 2007 (C23XB). Triumph Rocket 2300 III 2008 (C23XB). Triumph Rocket 2300 III 2009 (C23XB).

www.ebay.com

Aussie

throttle cable for Triumph Rocket 2300 III CLASSIC # 2006-2009 # T2043582 4251317940411 | eBay

Triumph Rocket 2300 III Classic 2004 (C23XB). Triumph Rocket 2300 III Classic 2005 (C23XB). Triumph Rocket 2300 III Classic 2006 (C23XB). Triumph Rocket 2300 III Classic 2007 (C23XB). Triumph Rocket 2300 III Classic 2008 (C23XB).

www.ebay.com.au

US $

throttle cable for Triumph Rocket 2300 III CLASSIC # 2006-2009 # T2043582 | eBay

Triumph Rocket 2300 III Classic 2004 (C23XB). Triumph Rocket 2300 III Classic 2005 (C23XB). Triumph Rocket 2300 III Classic 2006 (C23XB). Triumph Rocket 2300 III Classic 2007 (C23XB). Triumph Rocket 2300 III Classic 2008 (C23XB).

www.ebay.com

Aussie

throttle cable close for Triumph Rocket 2300 III Touring # T2043584 4251317943030 | eBay

Triumph Rocket 2300 III Touring 2007 (23XC). Triumph Rocket 2300 III Touring 2008 (23XC). Triumph Rocket 2300 III Touring 2009 (23XC). Triumph Rocket 2300 III Touring 2010 (23XC). Triumph Rocket 2300 III Touring 2011 (23XC).

www.ebay.com.au

US $

throttle cable close for Triumph Rocket 2300 III Touring # T2043584 | eBay

Triumph Rocket 2300 III Touring 2007 (23XC). Triumph Rocket 2300 III Touring 2008 (23XC). Triumph Rocket 2300 III Touring 2009 (23XC). Triumph Rocket 2300 III Touring 2010 (23XC). Triumph Rocket 2300 III Touring 2011 (23XC).

www.ebay.com

Aussie

throttle cable close for Triumph Rocket 2300 III # 2004-2014 # T2043575 4251317940398 | eBay

Triumph Rocket 2300 III 2004 (C23XB). Triumph Rocket 2300 III 2005 (C23XB). Triumph Rocket 2300 III 2006 (C23XB). Triumph Rocket 2300 III 2007 (C23XB). Triumph Rocket 2300 III 2008 (C23XB). Triumph Rocket 2300 III 2009 (C23XB).

www.ebay.com.au

US $

throttle cable close for Triumph Rocket 2300 III # 2004-2014 # T2043575 | eBay

Triumph Rocket 2300 III 2004 (C23XB). Triumph Rocket 2300 III 2005 (C23XB). Triumph Rocket 2300 III 2006 (C23XB). Triumph Rocket 2300 III 2007 (C23XB). Triumph Rocket 2300 III 2008 (C23XB). Triumph Rocket 2300 III 2009 (C23XB).

www.ebay.com
